Double Eccentric Butterfly Valve

Double Eccentric Butterfly Valve

Double Eccentric Butterfly Valve

Actuation

With mounted self-locking gear unit. Manual operation by one person.

Electric, Pneumatic and Hydraulic Actuator

Working Temperature

-20°C up to +70°C for liquids &
up to 120°C with special EPDM

Specifications

Design and Manufacturing as per IS 13095 / AWWA C 504 / BS EN 598 latest versions.

End Connection Flanges drilled as per IS / BS EN and ANSI relevant standard.

Size Range & Pressure

200 mm to 2000 mm,
PN 10 up to PN 16


(Higher sizes with larger pressure ratings available on request.)

Advantages

Valve body shall have integral hubs for housing, shaft bearing and seals.

Valve body shall have integral hubs for housing, shaft bearing and seals.

Valve body shall have integral hubs for housing, shaft bearing and seals.

Valve disc shall be of offset design to provide a full peripheral uninterrupted seating surface. Disc shall be convex shaped to minimize pressure drop and operating torque.

Valve disc shall be of offset design to provide a full peripheral uninterrupted seating surface. Disc shall be convex shaped to minimize pressure drop and operating torque.

Valve disc shall be of offset design to provide a full peripheral uninterrupted seating surface. Disc shall be convex shaped to minimize pressure drop and operating torque.

Resilient seal shall be synthetic rubber designed to provide leak proof shut off. Seal shall be incorporated on disc edge and shall be mechanically retained by means of a ring and stainless steel screws

Resilient seal shall be synthetic rubber designed to provide leak proof shut off. Seal shall be incorporated on disc edge and shall be mechanically retained by means of a ring and stainless steel screws

Resilient seal shall be synthetic rubber designed to provide leak proof shut off. Seal shall be incorporated on disc edge and shall be mechanically retained by means of a ring and stainless steel screws

Rubber seal interface can be adjusted at site. The seal is capable of being replaced in the field without removing valve from the line.

Rubber seal interface can be adjusted at site. The seal is capable of being replaced in the field without removing valve from the line.

Rubber seal interface can be adjusted at site. The seal is capable of being replaced in the field without removing valve from the line.
